Designed for even the most demanding installations, it simply out performs all others. Efficient, full-flow hydraulics produce more flow at equivalent horsepower, resulting in lower operating cost. Super II, when you want the very best.
- Self-primming-suction lift up to 8′ above water level
- Easy thread design makes strainer cover removal easy.
- Lexan see thru strainer cover lets you see when basket needs cleaning
- 180 cubic, inch basket has extra leaf folding capacity. Load extender ribbing ensure free flowing operation.
- All components molded of corrosion-proof PermaGlass XL for extra durability and long life
- Heavy duty, high perfomance motor for quieter, cooler operation.
- Service-ease design gives simple access to all internal parts.
- Includes Pump Lid removal Tool
|
Model
Full Rated |
PUMP Output (GPM) vs
Total Resistance to Flow
(feet to head) |
|
|
40 ft |
50 ft |
60 ft |
70 ft |
80 ft |
90 ft |
|
SP3007EEAZ |
78 |
67 |
56 |
38 |
– |
– |
|
SP3010EEAZ |
96 |
87 |
73 |
60 |
36 |
– |
|
SP3015EEAZ |
118 |
107 |
94 |
79 |
60 |
18 |
|
SP3020EEAZ |
138 |
125 |
112 |
96 |
75 |
43 |
|
SP3025EEAZ |
161 |
150 |
137 |
123 |
106 |
84 |
|
SP303063AZ |
161 |
150 |
137 |
123 |
106 |
84 |
| Model |
HP |
Voltage |
Pipe Size |
Dim
“A” |
| SP3010EEAZ |
1 |
220 |
2″ |
12 1/8″ |
| SP3015EEAZ |
1 1/2 |
220 |
2″ |
13 1/8″ |
| SP3020EEAZ |
2 |
220 |
2″ |
13 1/8″ |
| SP3025EEAZ |
3 |
220 |
2″ |
13 7/8″ |
| SP303063AZ |
3 |
380 |
2″ |
11 1/4″ |
